Wing span:1420mm
Length:1300mm
Engine:EDF or turbine\90EDF or a K30 \K45\X-45
Dry
Weight:3kg(Complete airframe with E-LG+E-Brakes)
Full airex composite
Available now......
Control info
Elevator : L -10 mm / H- 17mm
Rudder: -+20 mm
Ailerons: L-9mm /H- 13mm
Flaps : Take-off -20 mm,Landing -40mm
C.G. 150mm From the L.E.were the wing meets the fuselage.
JTM 90 viper with X-45 turbine NEW
Servos:GDW DS190c for flaps,ailerons,front gear door =5pc.
RS0708 or DS298MG for elevators,rudder and front gear =4pc.
If you need them can order from our local agent or PNP version.
Soft fuel tank 1000ml add soft smoke tank 500ml
Empty Weight: 4.6kg (no oil) full oil in main fuel tank about 5.5kg and full smoke tank 6kg
Flying weight 6 kg
Videos
JTM 90 viper with X-45 turbine NEW
Maiden Flight of JTM Viperjet 90mm powered by Jetcat turbine P20
P20:https://youtu.be/cI0mr-tzbXw?si=4DXJIuHjo-TKmlJC
JTM 90 Viper Onboard flight Kingtech K-45 90 size Vodafone colour scheme Cape Town SA
https://youtu.be/TjC_1V_v9e0?si=v2jIAPMw5Wiu7-W6
JTM RC 90Viper Jet Maiden Flight UsaRcJets
Jet Teng 90Viper Jet, Tamjets TJ90, NeuMotor 1412 2Y, Castle ICE HV120, Neu Lipos 10s 6200mAh.
https://youtu.be/pUI1JyduJVc?si=pgc6QhBdOCEAc4NI
Jerry Keller flying his 10s Jetfan 90 powered Jet Teng 90 Viper
https://youtu.be/qwJYT6Y9XwY?si=ERU_4lqKuxE1LRkT
https://youtu.be/J8uwI1Tu7q8?si=MoM-3DNTIeiCjWxN
JTM Viperjet 90 Vodafone 12s
JTM-90VP01#90 Viperjet Swiss
JTM-90VP02#90 Viperjet N520VF Red
JTM-90VP03#90 ViperjetN520VF Copper
JTM-90VP04#90 Viperjet Yellow
JTM-90VP05#90 Viperjet Blue+Silver
JTM-90VP06#90 Viperjet Black+Silver
JTM-90VP07#90 Viperjet Miss america
https://youtu.be/Xseq9cQGWWg New videoMiss america2025
90 viper Shipping cost(By plane)
To the USA\Canada\New Zealand\Australia\Italy\Norway\Spain\Danmark about 260 USD
To Portugal about 280 USD
To the UK\ Germany\Greece\ Switzerland\Sweden\France\Belgium\Holland\Luxembourg\Austria\Finland\about 210 USD
To Indonesia about 165 USD \To Singapore about 65 USD \To Thailand about 90 USD\To Japan about 85 USD
Feb 2025
